1. Versatile press for tire dismantling, straightening, assembly, and deformation work
2. Ideal for removing solid forklift tires
3. Double-column monolithic structure made of fully welded steel for maximum strength
4. Suitable for intensive workshop and industrial use
5. Large front opening for handling long and wide workpieces
6. Hollow work surface for flexible height processing (optional support table)
7. Hydraulic cylinder stroke of 500 mm
8. Option for fixed or transversal movable cylinder
9. Manual (handwheel) or hydraulic lateral movement depending on tonnage
| Specification | PFC 40 | PFC 70 | PFC 70 M | PFC 100 | PFC 100 M | PFC 100 MD | PFC 150 | PFC 150 M | PFC 150 MD | PFC 200 | PFC 200 M | PFC 200 MD | PFC 300 | PFC 300 MD | PFC 400 | PFC 400 MD |
| Tonnage | 40 | 70 | 70 | 100 | 100 | 100 | 150 | 150 | 150 | 200 | 200 | 200 | 300 | 300 | 400 | 400 |
| A | 2350 | 2350 | 2350 | 2400 | 2400 | 2400 | 2450 | 2450 | 2500 | 2500 | 2560 | 2560 | 2700 | 2700 | 2700 | 2850 |
| B | 1600 | 1700 | 1950 | 1950 | 2200 | 2400 | 2200 | 2500 | 3500 | 2550 | 2550 | 3050 | 2800 | 3300 | 2600 | 3400 |
| C | 900 | 900 | 900 | 1050 | 1050 | 1300 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1800 | 1800 | 1800 | 1800 |
| D | 900 | 900 | 900 | 1050 | 1050 | 1500 | 1500 | 1500 | 2000 | 1500 | 1500 | 2000 | 1500 | 2000 | 1500 | 2000 |
| F | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| X | FIXED | FIXED | 550 | FIXED | 600 | 1050 | FIXED | 800 | 1400 | FIXED | 880 | 1350 | FIXED | 1250 | FIXED | 1200 |
| Stroke | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
| Approach Speed | 29 | 20 | 20 | 25 | 25 | 25 | 22 | 22 | 22 | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Working Speed | 4 | 2 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Power (kW) | 1.5 | 1.5 | 1.5 | 2 | 2 | 2 | 4 | 4 | 4 | 4 | 4 | 4 | 7.5 | 7.5 | 7.5 | 7.5 |
| Weight (kg) | 630 | 740 | 780 | 1340 | 1450 | 1650 | 2400 | 2600 | 3000 | 3400 | 3600 | 4500 | 5200 | 5900 | 6200 | 7300 |
